- Compact yet powerful, this diesel forklift handles up to 1.5 ton with ease. Ideal for outdoor work or sites with uneven ground.
- Delivers strong torque and consistent lifting performance. Suitable for construction yards, freight depots, and heavy-duty applications.
- Refuelling is quick and easy, keeping downtime to a minimum. Great for operations that run multiple shifts or long hours.
- Designed for stable performance on rough or sloped terrain. Pneumatic tyres and solid build ensure safe, reliable handling.
- Fitted with a robust diesel engine built for durability. Handles tough conditions and extended use without compromising performance.
- Straightforward controls and a practical operator layout. Easy to learn and operate, even for less experienced drivers.
Parameters
|
Model |
FD15 |
|||
|
Power Type |
Diesel |
|||
|
Rated Capacity |
kg |
1500 |
||
|
Load Centre |
mm |
500 |
||
|
Lift Height |
mm |
3000 |
||
|
Fork Size(L×W×T ) |
mm |
920x120x35 |
||
|
Mast Tilt Angle(F/R) |
Deg |
6°/12° |
||
|
Front Overhang (Wheel center to fork face) |
mm |
410 |
||
|
Ground Clearance（Bottom of mast） |
mm |
110 |
||
|
Turning Radius (outside) |
mm |
2055 |
||
|
Max.Gradeability (No load/Full load) |
% |
20 |
||
|
Wheelbase |
mm |
1400 |
||
|
Service weight |
kg |
2820 |
||
|
Overall Dimension |
Length to face of fork(Without fork) |
mm |
2285 |
|
|
Overall Width |
mm |
1086 |
||
|
Mast Lowered Height |
mm |
1995 |
||
|
Mast Extended Height(With backrest) |
mm |
3940 |
||
|
Overhead Guard Height |
mm |
2040 |
||
|
Speed |
Travel (Full load) |
km/h |
15 |
|
|
Lifting (Full load) |
mm/s |
450 |
||
|
Tire |
Front |
mm |
6.50-10-12PR |
|
|
Rear |
mm |
5.00-8-10PR |
||
|
Battery |
Voltage/Capacity |
V/Ah |
12/80 |
|
|
Engine |
Model |
C240 |
NC485BPG-508 |
|
|
Manufacture |
NISSAN, KUBOTA, CUMMINS |
XINCHAI |
||
|
Rated output/r.p.m. |
kw |
35.4/2500 |
30/2600 |
|
|
Rated torque/r.p.m. |
N·m |
137.7/1800 |
131/1700-1900 |
|
|
No.of Cylinder |
4 |
4 |
||
|
Bore×Stroke |
mm |
86×102 |
85×100 |
|
|
Displacement |
cc |
2369 |
2270 |
|
|
Fuel Tank Capacity |
L |
45 |
45 |
|
|
Transmission |
Type |
Hydraulic |
Hydraulic |
|
|
Stage(FWD/RVS) |
1/1 |
1/1 |
||
